Continuous Motion Pre-Made Bag Packager – 24/7 Operation
| MOQ: | 1 |
| Preço: | Negotiations |
| Embalagem padrão: | Embalagem padrão internacional para envio |
| Período de entrega: | 30 dias |
| Método do pagamento: | L/C, T/T, Western Union |
| Capacidade de abastecimento: | 300 conjuntos por ano |
Informações pormenorizadas
Lugar de origem
Xangai
Marca
Waylead
Certificação
/
Número do modelo
WG-250
Documento
Velocidade de embalagem:
≦70 sacos/min
Tamanho da bolsa:
Comprimento:≦400mm largura:130-260mm
Material do filme:
Sacolas planas, bolsas verticais, bolsas com zíper, bolsas de filme composto e outros tipos.
Fonte de energia:
380 V
Consumo de ar:
5-7kg/cm2; 0,4m3/min
Tipo de energia:
Elétrico
Consumo de energia:
8 kw
Material:
Aço Sem Aço
Gama de embalagens:
Grânulos em pó líquido
Destacar:
Continuous motion Doypack packaging machine
,Pre-made bag packager 24/7 operation
,Doypack packaging machine with warranty
Descrição do produto
Rotary Filler Sealer for Preformed Pouches – Fast Changeover, 24/7 Operation
For manufacturers demanding uninterrupted production, this continuous motion pre-made bag packager delivers reliable performance across zipper, stand-up, and flat pouches. The rotary design eliminates start-stop motion, reducing mechanical wear and increasing output consistency.
The automatic bag loading system holds up to 300 preformed pouches in the magazine. Vacuum suckers open each bag while sensors verify full opening before product drops. Unopened bags are automatically rejected, preventing spillage into the seal area.
Sealing parameters adjust dynamically based on bag material – from polyethylene to laminated foil with zipper tracks. The resulting seal withstands transit and shelf handling, critical for reclosable packaging where consumers expect multiple open-close cycles.
This machine is built for 24/7 operation with sealed bearings and grease-packed moving parts. A remote diagnostic port allows our technicians to troubleshoot issues without visiting your factory. Available with 4, 6, 8, 10, or 12 stations. Typical applications include frozen fruits, granola, coffee beans, detergent powder, and liquid hand soap sachets.
Send your bag dimensions and product – we will provide a CAD layout showing how this rotary filler sealer integrates with your existing auger or multi-head scale.
Technical Specifications
| Specification | WG-210 | WG-250 | WG-300 |
|---|---|---|---|
| Bag Size | Length: 120-380mm Width: 90-210mm |
Length: ≤400mm Width: 130-260mm |
Length: ≤400mm Width: 160-300mm |
| Packing Speed | ≤70 bags/min | ≤70 bags/min | ≤65 bags/min |
| Work Stations | 8 | 8 | 8 |
| Packaging Formats | Flat bags, stand-up pouches, zipper bags, composite film pouches | Flat bags, stand-up pouches, zipper bags, composite film pouches | Flat bags, stand-up pouches, zipper bags, composite film pouches |
| Power Supply | 380V | 380V | 380V |
| Total Power | 8Kw | 8Kw | 8Kw |
| Air Consumption | 5-7kg/cm²; 0.4m³/min | 5-7kg/cm²; 0.4m³/min | 5-7kg/cm²; 0.4m³/min |
| Film Material | Single PE, PE composite film, paper film, various composite films | Single PE, PE composite film, paper film, various composite films | Single PE, PE composite film, paper film, various composite films |
| Machine Weight | 500kg | 580kg | 850kg |
| Machine Dimensions | 1700×1140×1470 mm | 1850×1250×1520 mm | 2100×1500×1520 mm |
Application Range
Block Items
Candy, chocolate, rock candy, biscuits, pastries, peanuts, green beans, pistachios, nuts, cooked food, pickles, puffed foods, daily necessities
Particles
MSG, chicken essence, sugar, melon seeds, nuts, capsules, granular medicines, seeds, feed, pesticides, fertilizers, chemical raw materials
Powders
Condiments, monosodium glutamate, salt, glucose, refined sugar, milk powder, washing powder, pesticides, fertilizers, chemical raw materials
Liquids
Rice wine, soy sauce, rice vinegar, juice, beverages, detergents
Sauces
Tomato sauce, peanut butter, jam, chili sauce, bean paste
Other Materials
Various other products suitable for bagging
Key Features & Advantages
GMP Compliance & CE Certification
Dual authoritative certifications meet stringent quality and safety requirements for pharmaceutical, food, and healthcare sectors. Streamlines global market access and eliminates international trade barriers while safeguarding product quality and consumer health.
Full Servo Control System
Ultra-reliable, high-speed precision operation with reduced equipment failure rates and unplanned downtime. Adapts flexibly to variable packaging rhythms and fulfills high-throughput production demands with pinpoint accuracy in material dosing, zipper doypack forming, and heat sealing.
Intelligent Empty Bag Tracking
Real-time detection of bag presence with instant interlock control to prevent empty bag sealing. Reduces packaging material waste, slashes manual sorting labor, lowers production costs, and enhances finished product purity.
8-Station Integrated Structure
Seamless connection of multiple packaging processes governed by programmable PLC system. Features 6 user-friendly flat touch screens and intuitive HMI interface for hassle-free parameter setting, real-time production monitoring, and quick troubleshooting. Lowers operator training threshold and guarantees long-term stable production.
Complete Packaging Solutions
Our comprehensive packaging range includes VFFS machines, flow wrapping machines, heat shrink packaging, pouch packing machines, and complete automated packaging lines with weight inspection, metal detection, carton packing, sealing, coding, and palletizing systems.
Frequently Asked Questions
Are you a trading company or a manufacturer?
We are a manufacturer, providing quality products at factory price. Welcome to visit us!
What quality guarantee or warranty do you provide?
We provide high-quality machines with a 3-year warranty and lifetime technical support.
When can I get the machine after payment?
Delivery time depends on the specific machine model ordered.
How do you provide technical support?
24/7 support via phone, email, or messaging platforms; installation guides and videos; overseas engineering services available.
How does your after-sales service work?
Machines are pre-adjusted before shipment with free training available. Lifetime technical support provided via multiple communication channels.
How about spare parts?
We provide a comprehensive spare parts list for reference.
Can you help with custom design requirements?
Customized design available with our experienced mechanical engineers.
Can you help analyze and design machines for new product samples?
Yes, our technical department can analyze, design, and test new products you provide.
How do I start an order?
30% deposit after signing contract, production arrangement, pre-shipment testing and inspection, balance payment before shipment.
Can you send product catalog and price list?
Electronic catalog available. Please consult us for specific product pricing.
Can I visit your factory?
Yes, welcome to visit our factory at Room 304, Wanchuangfang, No.155 Anzhi Road, Jiading District, Shanghai, China.
